Efficiency Driven by Performance
Standardized, configurable options and open customization possibilities offer versatility to adapt to a wide range of applications.
Advanced Integration Options
Available as a space saving combination system with metal detection or vision inspection technology.
Approved for all environments
The standardized, modular design with IP54, IP65 or IP69 rating delivers reliability and performance in dry, wet or harsh production environments.
Material No.: 2400330000
IP Rating | IP54 IP65 |
Compatible Software | ProdX |
Connectivity | Ethernet TCP/IP Fieldbus OPC UA |
Inspection Solution | Checkweighing |
Max Product Width | 400 mm |
Max Weighing Zones | 5 |
Weighing Technology | EMFR Strain Gauge |
HMI | 12" Touchscreen 7" Touchscreen |
Packaging Type | Bags Bottle Bundles Cardboard Cartons Cases Composite Cans Flow Packs Trays VFFS |
Product Flow | Conveyor |
Inspection Application | Completeness Check Weight Control |
Product Characteristic | Deep Frozen Dry Medium-Large Packages Open Round Container Small Individual Wrapped Products Small-Medium Packages Wet |
Industry | Chemical Food & Beverage Metal, Plastic and Electronics Components |
Weighing Accuracy | from ±0.05 g |
Industry Segment | Automotive Bakery and Confectionary Beer, Wine and Other Alcoholic Beverages Cosmetics Dairy Fine and Specialist Chemicals Food Additives Meat & Poultry & Seafood Nutraceuticals Oils and Fats Pet Food and Animal Feed Ready Meals Snack Foods Sugar Starch and Yeast Water and other Non-Alcoholic Beverages |
Max Product Weight | 7.5 kg |
Max Line Speed | 150 m/min |
Max Throughput | 350 ppm |
Data Governance to Support Performance
Over 10 different interface / protocol combinations including Ethernet, Fieldbus and OPC technologies enable IoT / Industry 4.0 initiatives so that production data can be accessed, analyzed and controlled anytime and anywhere.
Product Handling for Process Stability
A range of mechanical options increase process stability and Overall Equipment Efficiency (OEE) by reducing unexpected downtime. These include transition, transport and stability options for multiple packaging types and formats.
Software Options Increase Productivity
A large selection of enhanced software options help to increase productivity. These include process and fill level control, and statistical reporting for proof of compliance with industry standards.
Intuitive Operation
The system supports intuitive operation in over 30 languages via the 12" color touchscreen positioned in front of the conveyor for ease of use. Machine messages are communicated as clear text for easy understanding.
Easy to Clean
With only 4 feet on the floor, the system provides easy cleaning access whilst sloped surfaces prevent product retention. Easy conveyor belt changes and removable catch bins support fast cleaning across different environments.
Weighing Technology and Approval
Choose between the cost effective, robust strain gauge load cell or the high performance EMFR load cell with FlashCell™ technology. Optional MID certification helps to comply with local weighing regulations and reduces costly product waste.
Global Service Support
A global network of service experts provides fast remote and on-site support. Our comprehensive service offering supports regulatory compliance, high performance, and maximum uptime throughout the life cycle of your product inspection equipment.
