Magnetic Drive - 100 mL 2-Piece Reactor
Prevent Solvent Losses and Gas Leaks
Are you running reactions at boiling point, planning long-term experiments lasting a few days, or would like a reactor to be sealed hermetically and gas tight? Combined with glass reactors, the magnetic drive is the preferred solution for chemistry and development labs.
Designed for the EasyMax synthesis reactor system, the magnetic drive prevents solvent losses and gas leaks. The magnetic drive is corrosion-resistant and perfectly suited for reactions that consume gaseous products or produce off-gas.
For use with 100 mL 2-piece reactors, the EasyMax magnetic drive set includes all necessary items for vigorous stirring. Special kits are available to upgrade conventional overhead stirrer set-ups.
| Type | Magnetic Drive for 2-Piece 100 mL EasyMax Reactor | Magnetic Drive for 50 mL 2-Piece EasyMax Reactor |
| Suited For | 100 mL Glass Cover Set (51161709) 100 mL Cowie PTFE Cover Sets (30090541, 30090542) | 100 mL PTFE Cover Set (51161800) |
| Stirrer Shaft | 129 mm (length) | 94 mm (length) |
| Stirrer Blade | Pitch-blade downward 25 mm (diameter) | Pitch-blade downward 25 mm diameter |
| Material Wetted Parts | Alloy C-22, FFKM, PTFE C25 | Alloy C-22, FFKM (compound 6375), PTFE, PTFE C25 |
| Material Number | 30113925 | 30213866 |
Please note: Special Kits are available to upgrade conventional overhead stirrer set-ups.
