SWB505/SWC515 Multi-Purpose Weigh Modules | 0970 Ringmount Ultra-Flat Weigh Modules | 0970 Ringmount Redundant Weigh Modules | SWB220, VLM3, and SWD440 Economic Weigh Modules |
Multi-Purpose weigh modules SWB505 and SWC515 enable the quick and safe conversion of a tank, hopper, conveyor or structure system into a scale. | 0970 Ringmount weigh modules provide quick and safe conversion of tanks and vessels for process weighing. | 0970 Ringmount Redundant weigh modules provide the utmost in system reliability. | Economical weigh modules SWB220, VLM3, and SWD440 enable the conversion of tanks, hoppers, silos, and conveyors into a scale. |
Full Safety on Board All safety features integrated Easy Installation Locked for installation Versatile Wide range of accessories, EN1090 Versions Fully approved Global approvals as standard CalFree Weightless calibration | Ultra-Low Profile Requires less headroom Accurate Available in C6 OIML Durable 316 SS hardware standard Safe All safety features integrated Fully approved Global approvals standard | Redundant Sensors Reduce chance of downtime Accurate Available in C6 OIML Durable 316 SS hardware standard Safe All safety features integrated Fully approved Global approvals standard | Wide Capacity Range Available from 250lb to 250,000lb Carbon or Stainless Steel Hardware Mounting hardware to suit the environment Hazardous Area Approvals Load cells have FM or ATEX certification standard |
 |  |  | |
SWB305 and SWC415 Economic Weigh Modules | Strain Gauge Load Cells | Canister Load Cell / Ring Load Cell | CANBUS Converter Box CCB-4-X EN |
SWB305 and SWC415 Weigh Modules from METTLER TOLEDO enable the cost-effective conversion of tanks, hoppers, silos, and conveyors into a scale. | Strain gauge load cells are used in multiples (typically 3 or 4) in weighing systems, tank scales and conveyor scales. | Canister and ring load cells are used in tank and vessel scales, hopper scales, silo scales, vehicle scales and rail scales. | Model CCB-a-X converter box is an intrinsic safety device for installation in a hazardous area with IP68 rating. |
Wide Capacity Range Available from 100kg (250lb) to 100t (220klb) Carbon or Stainless Steel Hardware Mounting hardware to suit the environment Global Approvals Easy integration worldwide | Wide capacity range 5kg .. 4.4t (11lb .. 10klb) For mid-size weighing systems Process tanks, floor scales etc. Stainess Steel version Food and Pharma usage PowerCell versions For extreme accuracy requirements Reliable Performance Global approvals, Ex versions, IP69K | Wide capacity range 0.25t .. 300t (0.55klb .. 660klb) For heavy capacity weighing systems Tank-, silo-, hopper-, vehicle scales Coping with harsh environments Stainess Steel, IP69K versions For best reliability PowerCell versions Global Performance Global approvals, Ex versions |
CANBUS Barrier CBR-1-X EN | CANBUS Barrier CBR-2-X EN | CANBUS Barrier CBR-3-X EN | POWERCELL Zone 1/Div 1 Kit 1-4 LCs |
Model CBR-a-X barrier is installed in a non-hazardous area. It uses zener diodes and semiconductors to limit the energy delivered into the hazardous area. CBR-1 for 1-4 load cells. | Model CBR-a-X barrier is installed in a non-hazardous area. It uses zener diodes and semiconductors to limit the energy delivered into the hazardous area. CRB-2 for 5-8 load cells | Model CBR-a-X barrier is installed in a non-hazardous area. It uses zener diodes and semiconductors to limit the energy delivered into the hazardous area. CRB-3 for 9-12 load cells. | POWERCELL Zone 1/Div 1 includes a barrier, converter box and terminal to barrier home-run cable for 1-4 load cells. |
POWERCELL Zone 1/Div 1 Kit 5-8 LCs | POWERCELL Zone 1/Div 1 Kit 9-12 LCs | ||
POWERCELL Zone 1/Div 1 includes a barrier, converter box and terminal to barrier home-run cable for 5-8 load cells. | POWERCELL Zone 1/Div 1 includes a barrier, converter box and terminal to barrier home-run cable for 9-12 load cells. | ||
